YORK CHILLER 371 03788 336
Detail Information
INDEX NO.:
023-18249-000
NUMBER:
7—57
PART DESCRIPTION:
Flange Set With Gasket (2)
QTY.:
1
INDEX NO.:
025-40916-000
NUMBER:
7—54
PART DESCRIPTION:
Valve, Coolant Mixing (Valve Only)
INDEX NO.:
024-26954-000
NUMBER:
3—34
PART DESCRIPTION:
Contactor, Pre-Charge
INDEX NO.:
026-33890-000
NUMBER:
7—58
PART DESCRIPTION:
Pump, Coolant (After Reservoir)
INDEX NO.:
024-30441-000
NUMBER:
3—22
PART DESCRIPTION:
Relays, 1R1, 1R2, 2R1 (Coolant Pump, Fans)
QTY.:
3
INDEX NO.:
026-34461-000
NUMBER:
2—12
PART DESCRIPTION:
Assembly, Coil, Internal Cooling (912/752 HP)
INDEX NO.:
024-30992-000
NUMBER:
6—50
PART DESCRIPTION:
Contact, Blower Starter, 9 Amp
INDEX NO.:
026-35036-000
NUMBER:
7—56
PART DESCRIPTION:
Pump, Coolant (Before Heat Exchanger)
INDEX NO.:
024-33166-000
NUMBER:
6—49
PART DESCRIPTION:
Starter, Blower Motor
QTY.:
2
INDEX NO.:
026-43166-000
PART DESCRIPTION:
Assembly, Coil, Internal Cooling (700/572 HP)
INDEX NO.:
024-33169-000
NUMBER:
6—51
PART DESCRIPTION:
Starter, Oil Pump, 3HP (700/572 HP)
INDEX NO.:
031-01472-000
NUMBER:
3—28
PART DESCRIPTION:
Board, SCR Trigger, 60Hz
INDEX NO.:
024-33170-000
PART DESCRIPTION:
Starter, Oil Pump, 5HP
INDEX NO.:
031-01472-001
PART DESCRIPTION:
Board, SCR Trigger, 50Hz
INDEX NO.:
024-33171-000
PART DESCRIPTION:
Starter, Oil Pump, 7.5HP
INDEX NO.:
031-01624-000
NUMBER:
3—23
PART DESCRIPTION:
Board, VSD Bus Isolator
INDEX NO.:
024-33176-000
NUMBER:
6—48
PART DESCRIPTION:
Auxiliary Contacts, Blower Starter
NUMBER:
3—32
PART DESCRIPTION:
Board, Bus Isolator
INDEX NO.:
024-36147-000
NUMBER:
6—52
PART DESCRIPTION:
Contact, Oil Pump Starter
INDEX NO.:
031-01636-000
NUMBER:
3—26
PART DESCRIPTION:
Module, Diode
INDEX NO.:
025-34103-000
NUMBER:
2—17
PART DESCRIPTION:
Inductor, Filter (912/752 HP)
INDEX NO.:
031-01644-000
NUMBER:
3—24
PART DESCRIPTION:
Varistor, Metal Oxide
INDEX NO.:
025-17407-000
NUMBER:
1—1
PART DESCRIPTION:
Fuse Holder
QTY.:
10
INDEX NO.:
031-02022-000
NUMBER:
3—31
PART DESCRIPTION:
Board, Line Voltage Isolation
INDEX NO.:
025-25515-000
NUMBER:
1—7
PART DESCRIPTION:
Fuse, 7 Amp
INDEX NO.:
071-01746-326
NUMBER:
4—38
PART DESCRIPTION:
Insulator, Bus Plate
INDEX NO.:
025-27699-000
NUMBER:
1—5
PART DESCRIPTION:
Fuse, 30 Amp
INDEX NO.:
224-36981-000
NUMBER:
2—10
PART DESCRIPTION:
Circuit Breaker, 1100 Amp With GFCI (700/572 HP)
INDEX NO.:
025-27911-000
NUMBER:
3—21
PART DESCRIPTION:
Transformer, 3T, 24 V AC
INDEX NO.:
224-36982-000
PART DESCRIPTION:
Circuit Breaker, 1200 Amp With GFCI (912/752 HP)
INDEX NO.:
025-28967-000
NUMBER:
1—6
PART DESCRIPTION:
Fuse, 20 Amp
INDEX NO.:
331-02506-605
NUMBER:
1—8
PART DESCRIPTION:
Board, VSD Logic
INDEX NO.:
025-29627-002
NUMBER:
3—18
PART DESCRIPTION:
Transformer, Control, 2 KVa, 60 Hz
INDEX NO.:
371-01746-321
NUMBER:
4—37
PART DESCRIPTION:
Bus Plate, Negative
INDEX NO.:
025-29627-003
PART DESCRIPTION:
Transformer, Control, 2 KVa, 50 Hz
INDEX NO.:
025-30986-000
NUMBER:
5—46
PART DESCRIPTION:
Resistor, Output Network, DV/DT
QTY.:
6
INDEX NO.:
025-30987-000
NUMBER:
5—47
PART DESCRIPTION:
Capacitor, Output Network, DV/DT
INDEX NO.:
025-31499-000
NUMBER:
3—19
PART DESCRIPTION:
Transformer, Control, 3 KVa, 60 Hz
INDEX NO.:
371-01746-341
NUMBER:
4—39
PART DESCRIPTION:
Bus Plate, Positive
INDEX NO.:
025-31700-000
NUMBER:
3—20
PART DESCRIPTION:
Resistor, Pre-charge (700/572 HP)
INDEX NO.:
371-01748-328
NUMBER:
2—15
PART DESCRIPTION:
Assembly, Filter Trap (700/572 HP)
PART DESCRIPTION:
Resistor, Pre-charge (912/752 HP)
INDEX NO.:
371-01749-448
NUMBER:
5—45
PART DESCRIPTION:
Assembly, Output Network, DV/DT
INDEX NO.:
025-32502-000
NUMBER:
3—30
PART DESCRIPTION:
Resistors, Filter Pre-Charge
INDEX NO.:
371-01752-001
NUMBER:
5—44
PART DESCRIPTION:
Kit, Replacement, Input Rectifier (700/572 HP)
INDEX NO.:
025-32557-000
NUMBER:
2—13
PART DESCRIPTION:
Fan, Internal Cooling
INDEX NO.:
371-02517-344
NUMBER:
4—41
PART DESCRIPTION:
Assembly, Filter Pole Replacement (912/752 HP)
INDEX NO.:
025-32832-000
NUMBER:
2—14
PART DESCRIPTION:
Inductor, DC Link (700/572 HP)
INDEX NO.:
371-02528-315
NUMBER:
3—29
PART DESCRIPTION:
Contactor, Filter Input (700/572 HP)
INDEX NO.:
025-32833-000
NUMBER:
2—16
PART DESCRIPTION:
Fuses, Filter Line, 300 Amp (700/572 HP)
INDEX NO.:
371-02535-101
NUMBER:
1—15
PART DESCRIPTION:
Assembly, Filter Trap (912/752 HP)
INDEX NO.:
025-32842-000
PART DESCRIPTION:
Inductor, Filter (700/572 HP)
INDEX NO.:
371-02536-001
NUMBER:
5—43
PART DESCRIPTION:
Kit, Replacement, Input SCR (912/752 HP)
INDEX NO.:
025-32914-000
NUMBER:
2—11
PART DESCRIPTION:
Fuse, Semi-conductor, 1100 Amp (700/572 HP)
INDEX NO.:
371-02537-001
NUMBER:
5—42
PART DESCRIPTION:
Kit, Replacement, Input Diode (912/752 HP)
INDEX NO.:
025-32923-000
NUMBER:
3—33
PART DESCRIPTION:
Sensor, Electronic Current, 1000 Amp (700/572 HP)
INDEX NO.:
371-02744-001
PART DESCRIPTION:
Assembly, Filter Pole Replacement (700/572 HP)
INDEX NO.:
025-32983-000
PART DESCRIPTION:
Transformer, Control, 3 KVa, 50 Hz
INDEX NO.:
371-05042-100
NUMBER:
4—36
PART DESCRIPTION:
Resistor, DC Balancing
INDEX NO.:
025-34104-000
PART DESCRIPTION:
Inductor, DC Link (912/752 HP)
INDEX NO.:
371-05150-401
NUMBER:
7—60
PART DESCRIPTION:
Reservoir, Coolant
INDEX NO.:
025-34139-000
NUMBER:
1—2
PART DESCRIPTION:
Fuse, 10 Amp, 3HP Oil Pump
INDEX NO.:
371-05150-411
NUMBER:
7—55
PART DESCRIPTION:
Heat Exchanger, Plate
INDEX NO.:
025-34141-000
PART DESCRIPTION:
Fuse, 15 Amp, 5HP Oil Pump
INDEX NO.:
371-05172-344
NUMBER:
4—40
PART DESCRIPTION:
Assembly, Replacement, VSD Output Pole (700/572 HP)
INDEX NO.:
025-34142-000
PART DESCRIPTION:
Fuse, 20 Amp, 7.5HP Oil Pump
INDEX NO.:
371-05238-344
PART DESCRIPTION:
Assembly, Replacement, VSD Output Pole (912/752 HP)
INDEX NO.:
025-34166-000
PART DESCRIPTION:
Fuse, Semi-conductor, 1600 Amp (912/752 HP)
INDEX NO.:
531-01701-001
NUMBER:
3—25
PART DESCRIPTION:
Transformer, Output Current (700/572 HP)
INDEX NO.:
025-34167-000
PART DESCRIPTION:
Fuses, Filter Line, 500 Amp (912/752 HP)
NUMBER:
3—35
PART DESCRIPTION:
Transformer, Input Current (700/572 HP)
INDEX NO.:
025-34168-000
PART DESCRIPTION:
Sensor, Electronic Current, 1200 Amp (912/752 HP)
INDEX NO.:
531-02026-001
PART DESCRIPTION:
Transformer, Output Current (912/752 HP)
INDEX NO.:
025-35905-000
NUMBER:
1—4
PART DESCRIPTION:
Fuse, 10 Amp
PART DESCRIPTION:
Transformer, Input Current (912/752 HP)
INDEX NO.:
025-35907-000
NUMBER:
1—3
PART DESCRIPTION:
Fuse, 15 Amp
INDEX NO.:
571-01743-101
NUMBER:
3—27
PART DESCRIPTION:
Contactor, VSD Pre-Charge
INDEX NO.:
025-40386-000
NUMBER:
7—53
PART DESCRIPTION:
Actuator, Coolant Mixing Valve
INDEX NO.:
025-40387-000
NUMBER:
7—59
PART DESCRIPTION:
Sensor, Vyper Coolant Temp. (Reservoir)
Product Description
YORK/JCI Chiller Service Parts
SERVICE PARTS LIST for YORK/JCI chillers, specifically relating to the Optional Harmonic Filter for 700/572 HP & 912/752 HP models. This list provides detailed information on components required for maintenance and repair.
- Genuine YORK/JCI parts for optimal performance.
- Comprehensive list for easy part identification.
- Ensures proper fit and function.
- Supports chiller maintenance and longevity.
Target Industries: HVAC, Industrial Refrigeration, Building Maintenance
Applications: Chiller maintenance, repair, and component replacement.
Product Attributes
Brand:
YORK/JCI
Model Number:
371 03788 336
Place of Origin:
United States
Minimum Order Quantity:
1
Technical Specifications
| INDEX NO. | NUMBER | PART DESCRIPTION | QTY. |
|---|---|---|---|
| 023-18249-000 | 7—57 | Flange Set With Gasket (2) | 1 |
| 025-40916-000 | 7—54 | Valve, Coolant Mixing (Valve only) | 1 |
| 024-26954-000 | 3—34 | Contactor, Pre-Charge | 1 |
| 026-33890-000 | 7—58 | Pump, Coolant (After Reservoir) | 1 |
| 024-30441-000 | 3—22 | Relays, 1R1, 1R2, 2R1 (Coolant Pump, Fans) | 3 |
| 026-34461-000 | 2—12 | Assembly, Coil, Internal Cooling (912/752 HP) | 1 |
| 024-30992-000 | 6—50 | Contact, Blower Starter, 9 Amp | 1 |
| 026-35036-000 | 7—56 | Pump, Coolant (Before Heat Exchanger) | 1 |
| 024-33166-000 | 6—49 | Starter, Blower Motor | 2 |
| 026-43166-000 | 2—12 | Assembly, Coil, Internal Cooling (700/572 HP) | 1 |
| 024-33169-000 | 6—51 | Starter, Oil Pump, 3HP (700/572 HP) | 1 |
| 031-01472-000 | 3—28 | Board, SCR Trigger, 60Hz | 1 |
| 024-33170-000 | 6—51 | Starter, Oil Pump, 5HP | 1 |
| 031-01472-001 | 3—28 | Board, SCR Trigger, 50Hz | 1 |
| 024-33171-000 | 6—51 | Starter, Oil Pump, 7.5HP | 1 |
| 031-01624-000 | 3—23 | Board, VSD Bus Isolator | 1 |
| 024-33176-000 | 6—48 | Auxiliary Contacts, Blower Starter | 2 |
| 031-01624-000 | 3—32 | Board, Bus Isolator | 1 |
| 024-36147-000 | 6—52 | Contact, Oil Pump Starter | 1 |
| 031-01636-000 | 3—26 | Module, Diode | 1 |
| 025-34103-000 | 2—17 | Inductor, Filter (912/752 HP) | 1 |
| 031-01644-000 | 3—24 | Varistor, Metal Oxide | 3 |
| 025-17407-000 | 1—1 | Fuse Holder | 10 |
| 031-02022-000 | 3—31 | Board, Line Voltage Isolation | 1 |
| 025-25515-000 | 1—7 | Fuse, 7 Amp | 1 |
| 071-01746-326 | 4—38 | Insulator, Bus Plate | 1 |
| 025-27699-000 | 1—5 | Fuse, 30 Amp | 1 |
| 224-36981-000 | 2—10 | Circuit Breaker, 1100 Amp with GFCI (700/572 HP) | 1 |
| 025-27911-000 | 3—21 | Transformer, 3T, 24 V AC | 1 |
| 224-36982-000 | 2—10 | Circuit Breaker, 1200 Amp with GFCI (912/752 HP) | 1 |
| 025-28967-000 | 1—6 | Fuse, 20 Amp | 1 |
| 331-02506-605 | 1—8 | Board, VSD Logic | 1 |
| 025-29627-002 | 3—18 | Transformer, Control, 2 kVa, 60 Hz | 1 |
| 371-01746-321 | 4—37 | Bus Plate, Negative | 1 |
| 025-29627-003 | 3—18 | Transformer, Control, 2 kVa, 50 Hz | 1 |
| 025-30986-000 | 5—46 | Resistor, Output Network, DV/DT | 6 |
| 025-30987-000 | 5—47 | Capacitor, Output Network, DV/DT | 6 |
| 025-31499-000 | 3—19 | Transformer, Control, 3 kVa, 60 Hz | 1 |
| 371-01746-341 | 4—39 | Bus Plate, Positive | 1 |
| 025-31700-000 | 3—20 | Resistor, Pre-charge (700/572 HP) | 2 |
| 371-01748-328 | 2—15 | Assembly, Filter Trap (700/572 HP) | 1 |
| 025-31700-000 | 3—20 | Resistor, Pre-charge (912/752 HP) | 3 |
| 371-01749-448 | 5—45 | Assembly, Output Network, DV/DT | 1 |
| 025-32502-000 | 3—30 | Resistors, Filter Pre-Charge | 3 |
| 371-01752-001 | 5—44 | Kit, Replacement, Input Rectifier (700/572 HP) | 3 |
| 025-32557-000 | 2—13 | Fan, Internal Cooling | 6 |
| 371-02517-344 | 4—41 | Assembly, Filter Pole Replacement (912/752 HP) | 1 |
| 025-32832-000 | 2—14 | Inductor, DC Link (700/572 HP) | 1 |
| 371-02528-315 | 3—29 | Contactor, Filter Input (700/572 HP) | 1 |
| 025-32833-000 | 2—16 | Fuses, Filter Line, 300 Amp (700/572 HP) | 3 |
| 371-02535-101 | 1—15 | Assembly, Filter Trap (912/752 HP) | 1 |
| 025-32842-000 | 2—17 | Inductor, Filter (700/572 HP) | 1 |
| 371-02536-001 | 5—43 | Kit, Replacement, Input SCR (912/752 HP) | 3 |
| 025-32914-000 | 2—11 | Fuse, Semi-conductor, 1100 Amp (700/572 HP) | 3 |
| 371-02537-001 | 5—42 | Kit, Replacement, Input Diode (912/752 HP) | 3 |
| 025-32923-000 | 3—33 | Sensor, Electronic Current, 1000 Amp (700/572 HP) | 2 |
| 371-02744-001 | 4—41 | Assembly, Filter Pole Replacement (700/572 HP) | 1 |
| 025-32983-000 | 3—19 | Transformer, Control, 3 kVa, 50 Hz | 1 |
| 371-05042-100 | 4—36 | Resistor, DC Balancing | 2 |
| 025-34104-000 | 2—14 | Inductor, DC Link (912/752 HP) | 1 |
| 371-05150-401 | 7—60 | Reservoir, Coolant | 1 |
| 025-34139-000 | 1—2 | Fuse, 10 Amp, 3HP Oil Pump | 3 |
| 371-05150-411 | 7—55 | Heat Exchanger, Plate | 1 |
| 025-34141-000 | 1—2 | Fuse, 15 Amp, 5HP Oil Pump | 3 |
| 371-05172-344 | 4—40 | Assembly, Replacement, VSD Output Pole (700/572 HP) | 3 |
| 025-34142-000 | 1—2 | Fuse, 20 Amp, 7.5HP Oil Pump | 3 |
| 371-05238-344 | 4—40 | Assembly, Replacement, VSD Output Pole (912/752 HP) | 3 |
| 025-34166-000 | 2—11 | Fuse, Semi-conductor, 1600 Amp (912/752 HP) | 3 |
| 531-01701-001 | 3—25 | Transformer, Output Current (700/572 HP) | 3 |
| 025-34167-000 | 2—16 | Fuses, Filter Line, 500 Amp (912/752 HP) | 3 |
| 531-01701-001 | 3—35 | Transformer, Input Current (700/572 HP) | 2 |
| 025-34168-000 | 3—33 | Sensor, Electronic Current, 1200 Amp (912/752 HP) | 2 |
| 531-02026-001 | 3—25 | Transformer, Output Current (912/752 HP) | 3 |
| 025-35905-000 | 1—4 | Fuse, 10 Amp | 2 |
| 531-02026-001 | 3—35 | Transformer, Input Current (912/752 HP) | 2 |
| 025-35907-000 | 1—3 | Fuse, 15 Amp | 2 |
| 571-01743-101 | 3—27 | Contactor, VSD Pre-Charge | 1 |
| 025-40386-000 | 7—53 | Actuator, Coolant Mixing Valve | 1 |
| 025-40387-000 | 7—59 | Sensor, Vyper Coolant Temp. (Reservoir) | 1 |
Recommended Products
Chat Now
Chat Now
Chat Now
Chat Now
Chat Now
Chat Now
Chat Now
Chat Now
